RJ45 8P10C
RJ45 TRANSFORMER » RJ45 TRANSFORMER
NO : 8-7-RJS1x1111G

  • RJ45 jack without Transformer

RJ45 8P10C, W/1G, W/LED, SHIELDED, VERTICAL TYPE

DETAIL INFORMATION

1. MATERIAL:

HOUSING: HIGH THERMOPLASTIC, UL94V-0, BLACK

CONTACTS: T=0.35mm PHOS-BRONZE, 6u" GOLD PLATING ON CONTACT AREA, NICKEL UNDERPLATING OVERALL

SHIELD: COPPER ALLOY, NICKEL PLATING

2. NUMBER OF PORT: 1*1

3.SPEED: 1G

4. LED: YELLOW/ GREEN

5. OPERATING TEMPERATURE: 0°C~+70°C

6. INSERTION FORCE: 4 POUNDS MAX.

  EXTRACTION FORCE: 4 POUNDS MAX.

7. DURABILITY: 750 MATING CYCLED MIN.

8. CAVITY CONFORMS TO FCC RULES AND REGULATIONS PART 68, SUBPART F.
